HDPE/PVC/PE Feeding and Screw Extruder Double Wall Corrugated Pipe Extrusion Line
| Brand Name | HUASU |
|---|---|
| Certification | CE,ISO |
| Model Number | SBG- |
| Minimum Order Quantity | 1 SET |
| Price | 10K-1M |
| Packaging Details | Container Standard Packaging |
| Delivery Time | 60-90days |
| Payment Terms | T/T |
| Supply Ability | 100SET/year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Type | Double Wall Corrugated Pipe Extrusion Line | Control System | PLC Control System And Touch Screen |
|---|---|---|---|
| Rocessing Procedure | Raw Material Feeding In Screw Extruder, Shaping In Forming Machine ,Water Cooling Tank Cooling,online Cut By Cutting Machine | Pipe Diameter | 32-1600mm |
| Capacity | 60-2000kg/h | Application | Drainage/Sewege/Cable Duct/Electric Conduit/Fresh Air Ventilation Pipe |
| Finished Product | Drainage Pipe,municipal Engineering,underground Sewage Pipe,electric Cable Conduit | Electric Element | Siemens Brand |
Product Description
HDPE/PVC/PE Feeding and Screw Extruder Double Wall Corrugated Pipe Extrusion Line
Product Description:
The double wall corrugated pipe line is Shandong HUASU's 3rd generation improved product. Compared to the previous product, the extruder output and pipe production speed are significantly increased by 20-40%.
Online belling is possible to guarantee the performance of the formed corrugated pipe products. The production line is equipped with a Siemens PLC system for efficient control and management.
Features:
Pressure water-cooling is utilized to enhance the production speed of mould blocks, leading to increased efficiency in manufacturing.
One of the advantages of this system is its low energy consumption, which contributes to reducing overall production costs.
An efficient vacuum system is implemented to ensure the formation of flawless pipes during the manufacturing process.
The temperature control system of mould blocks is designed to optimize the quality of pipes, focusing on both external appearance and internal structure.
Changing between different sizes of moulds is made easy and quick, allowing for seamless transitions and compatibility with various production lines.
The entire extrusion line is operated in a fully automatic mode, streamlining the production process.
The corrugator and extruders are synchronized, enabling smooth and coordinated control throughout the manufacturing operation.
Screws and barrels undergo hardening treatment to extend their lifespan and enhance durability in the production environment.
Remote service options are available to provide support and assistance as needed.
Technical Parameters:
| Finished Product | Drainage Pipe, Municipal Engineering, Underground Sewage Pipe, Electric Cable Conduit |
|---|---|
| Product Type | Double Wall Corrugated Pipe Extrusion Line |
| Electric Element | Siemens Brand |
| Application | Drainage/Sewage/Cable Duct/Electric Conduit/Fresh Air Ventilation Pipe |
| Processing Procedure | Raw Material Feeding In Screw Extruder, Shaping In Forming Machine, Water Cooling Tank Cooling, Online Cut By Cutting Machine |
| Plastic Raw Material Processed | PVC/PE/MPP/PA/HDPE |
| Pipe Diameter | 32-1600mm |
| Capacity | 60-2000kg/h |
| Control System | PLC Control System And Touch Screen |
| Features | High Productivity, Competitive Price, Energy Saving, Automatic |
Applications:
The Plastic Pipe Making Machine we offer is specially designed for producing plastic pipes used in water supply, water drainage, and electric cable conduits. It is engineered to manufacture high-quality plastic pipes that meet the standards for different applications, including water transportation, drainage systems, and electric cable protection.
This machine is meticulously crafted to ensure the production of top-notch plastic pipes suitable for a variety of uses. It is equipped with advanced technology and features to guarantee efficient manufacturing processes while meeting the specific requirements of water supply, drainage, and electric cable conduit systems.
