Qingdao High Speed DWC Pipe Extrusion Line / Double Wall Corrugated Pipe Production Machine

Qingdao High Speed DWC Pipe Extrusion Line / Double Wall Corrugated Pipe Production Machine

  • Qingdao High Speed DWC Pipe Extrusion Line / Double Wall Corrugated Pipe Production Machine
  • Qingdao High Speed DWC Pipe Extrusion Line / Double Wall Corrugated Pipe Production Machine
  • Qingdao High Speed DWC Pipe Extrusion Line / Double Wall Corrugated Pipe Production Machine
  • Qingdao High Speed DWC Pipe Extrusion Line / Double Wall Corrugated Pipe Production Machine
  • Qingdao High Speed DWC Pipe Extrusion Line / Double Wall Corrugated Pipe Production Machine
Qingdao High Speed DWC Pipe Extrusion Line / Double Wall Corrugated Pipe Production Machine
Product Details:
Place of Origin: QINGDAO CHINA
Brand Name: QINGDAO HAUSU
Certification: CE IOS9001
Model Number: SBG-600
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD 19000.00-20000.00/set
Packaging Details: NORMAL PACKAGE
Delivery Time: 5-8work days
Payment Terms: L/C
Supply Ability: 100sets/year
Contact Now
Detailed Product Description
Machine Name: Double Wall Corrugated Pipe Extruder Temperature Controller: Temperature Sensor
Product Name: Double Wall Corrugated Pipe Extruder Machine: Corrugated Pipe Line
Product Type: Plastic Pipe Forming
High Light:

dwc pipe machine

,

ppr pipe extrusion line

   Qingdao High Speed DWC Pipe Extrusion Line / Double Wall Corrugated Pipe Production Machine 0

         In order to meet the demand of plastic pipe market,HUASU Company designed and developed this HIGH SPEED Double Wall Corrugated Pipe Extrusion Line by absorbing advanced technology from foreign countries plastic machinery industry. This Corrugated Pipe Extrusion Line is the latest study achievement in the plastic extrusion field. This extrusion line is suitable for the high speed extrusion of HDPE,LDPE and PP material. HDPE Double Wall Corrugated Pipe Extrusion Line adopts directly extruding ( two extruders'co-extrusion) and forming technology,human-machine interface control system. It makes high automation degree,reliable quality and stable production become true. And this pipe production line wins our home and abroad customers' good reputation.

       1. All-new mould blocks cooling method. The mould blocks are cooled continuously by“pressure cooling” water circulating in sealed channels to achieve higher cooling efficiency and higher production speed, which strongly guarantee lower pipe production cost.
       2. Highly compatible technical solution of mould blocks. The mould blocks can be compatible between different models of production lines in order to make the production more flexible with lower maintenance cost.
       3. All-new design of “none platform” for corrugator. Need not to adjust the height of corrugator when change the moulds for different sizes. Operations become easier and more efficient.
       4. Innovative rapid assembly of mould blocks in clasp style simplifies the

Model pipe diameter Installed power Mould block Chain length Max.output Max.operating speed
SBG600 ID110-600mm 395kw 36pair 6333mm 1350kg/h 6.5m/min
