250kw 200mm Gas Distribution HDPE Pipe Extrusion Line
| Place of Origin | CHINA |
|---|---|
| Brand Name | SD Huasu Brand |
| Certification | CE, ISO9001:2008, UL, QS, GMP |
| Model Number | SRQG-250 |
| Minimum Order Quantity | 1 SET |
| Packaging Details | STANDARD PACKAGE |
| Delivery Time | 30 WORKING DAYS |
| Payment Terms | T/T |
| Supply Ability | 50 SETS/MONTH |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Pipe Diameter | 75/90/110/115/140/160/180/200/250 | Other Diameter | Available |
|---|---|---|---|
| Total Power | 250kw | Extruder 90/30 | Bigger One 132kw For Extrude Pipes |
| Extruder 30/25 | Smaller One 1.5kw For Extrude Color Lines Fro Marking | ||
| Highlight | 200mm HDPE Pipe Extrusion Line,250kw HDPE Pipe Extrusion Line,0.3m3/Min HDPE Pipe Extrusion Line |
||
Product Description
PE Plain Pipes Machine For Water Supply And Gas Distribution Application
|
NO. |
Inner Diameter( mm) |
Outside Diameter ( mm) |
Remark |
| 1 | 75 | ||
| 2 | 90 | ||
| 3 | 110 | ||
| 4 | 125 | ||
| 5 | 140 | ||
| 6 | 160 | ||
| 7 | 180 | ||
| 8 | 200 | ||
| 9 | 250 |
Environment Condition
| Location | Workshop |
| Power Supply | No dangerous area, No power stop area |
| Humidity degree | ≤95% |
| Temperature | 0-36℃ |
Work Condition
| Power | 380 V x 50 Hz x 3 Phase |
|
Total Power
|
250kw |
|
Cooling Water
|
Recycling water. ≤20℃, ≥0.3Mpa, ～8M3/h |
|
Compressed air
|
0.3m3/min, ＞1.2Mpa |
|
Line Dimension
|
47 m *3 m * 2.5 m |
Main Technical Performance
|
Extruder |
Motor |
Max Output |
Note |
| SJ90/33 | 132kw | 300-450kg/h | |
| SJ30/25 | 1.5kw | 5-10kg/h |
