220kg/H Anti Flammable Hdpe Pipe Extrusion Line 63mm Diameter

Product Details:

Place of Origin:	CHINA
Brand Name:	SD Huasu Brand
Certification:	CE, ISO9001:2008, UL, QS, GMP
Model Number:	PE single wall corrugated pipe extrusion line

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Packaging Details:	standard package or as required
Delivery Time:	30 working days
Payment Terms:	T/T
Supply Ability:	50 sets/month

Contact Now

Detailed Product Description

Product:	Die Head	Plastic Processed:	LDPE, HDPE
Screw Material:	38CrMoALA	Screw L/D Ratio:	33:1
Extruder:	2 Sets
High Light:	Anti Flammable HDPE Pipe Extrusion Line , 220kg/H HDPE Pipe Extrusion Line , Dia 63mm HDPE Pipe Extrusion Line

Widely High Quality PE Pipe Extruders Plastic Production Line/Making Machine/Pvc Extrusion Line Products On Sale

Widely High Quality PE Pipe Extruders Plastic Production Line/Making Machine/Pvc Extrusion Line Products On Sale

HDPE pipe extrusion line is primarily used in the manufacturing of PE pipes with diameters ranging from 16mm to 1600mm. The various thickness of the pipes produced can make them suitable for applications range from urban water supply to gas transportation. It also excels in the production of anti-flammable and anti-static electricity pipes using a two or three layer spiral mould for use in mining industries. Pipes produced feature even wall-thickness and perfect roundness. Through switching or adding certain part of machine unit, this line can also be customized to extrude pipes of various other kinds.

TECHNICAL PARAMETERS (33D)
Model	Pipe diameter	Extruder	Max. output	Haul-off speed	Motor power
PE63	16-63mm	SJ65/33	220kg/h	12m/min	55kW
PE110	20-110mm	SJ65/33	220kg/h	12m/min	55kW
PE160	50-160mm	SJ75/33	300kg/h	10m/min	90kW
PE250	90-250mm	SJ75/33	400kg/h	8m/min	110kW
PE450	160-450mm	SJ90/33	500kg/h	5m/min	160kW
PE630	315-630mm	SJ120/33	850kg/h	3.3m/min	280kW
PE800	500-800mm	SJ120/33	1000kg/h	1.8m/min	315kW
PE1200	710-1200mm	SJ150/33	1300kg/h	0.8m/min	355kW
TECHNICAL PARAMETERS (38D)
Model	Pipe diameter	Extruder	Max. output	Haul-off speed	Motor power
PE63	16-63mm	SJ60/38	320kg/h	30m/min	70kW
PE110	20-110mm	SJ60/38	380kg/h	20m/min	90kW
PE160	40-160mm	SJ60/38	460kg/h	15m/min	110kW
PE250	50-250mm	SJ75/38	600kg/h	12m/min	160kW
PE450	110-450mm	SJ90/38	850kg/h	8m/min	250kW
PE630	250-630mm	SJ90/38	1050kg/h	4m/min	280kW
PE800	500-800mm	SJ120/38	1300kg/h	2m/min	315kW
PE1200	710-1200mm	SJ120/38	1400kg/h	1m/min	355kW
PE1600	1000-1600mm	SJ90/38&SJ90/38	1600kg/h	0.6m/min	2*280kW
