60kg/H 45mm Screw Corrugated Pipe Extrusion Line Horizontal Type
| Place of Origin | CHINA |
|---|---|
| Brand Name | SD Huasu Brand |
| Certification | CE, ISO9001:2008, UL, QS, GMP |
| Model Number | standard type |
| Minimum Order Quantity | 1 SET |
| Packaging Details | standard package or as required |
| Delivery Time | 30 working days |
| Payment Terms | T/T |
| Supply Ability | 50 sets/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Plastic Processed | PE/PP/PVC | Screw Design | Single-screw |
|---|---|---|---|
| Screw Diameter | 45mm | Voltage | 380V Or Optional |
| Dimension(L*W*H) | 4.7m*1.5m*2.4m | Certification | CE ISO |
| Highlight | 45mm Screw Corrugated Pipe Extrusion Line,380V Horizontal Corrugated Pipe Extrusion Line,60kg/H Corrugated Pipe Extrusion Line |
||
Product Description
PVC/PP/PE Single Wall Corrugated Pipe Extrusion Line Horizontal Type
1)Pvc production line can be used to produce single-wall corrugated pipe.
2) Characteristic :
Plastic single-wall corrugated pipes have features of high temperature resistance, resistant to corrosion and abrasion, high intensity, good flexibility, etc.Plastic single-wall corrugated pipe production line developed by our company adopts gears to run moulds and templates so as to realize water circulating cooling and air cooling of the products, which ensures high-speed molding, even corrugation, smooth inner and outer pipe wall. These corrugated pipes are especially used as wires of the up-market cars.
3) APPLICATION: They are widely used in fields of auto wire, electric thread-passing pipes, circuit of machine tool, protective pipes of lamps and lanterns wire, tubes of air conditioner and washing machine, etc.
| No. | Model | Qty |
| 1 | Feeder | 1set |
| 2 | Single-screw extruder | 1set |
| 3 | Corresponding Single-wall Corrugated pipe extruding die | 1set |
| 4 | Single-wall Corrugated Pipe Molding Machine | 1set |
| 5 | Reeling Machine | 1set |
| 6 | Meter Recorder | 1set |
| Pipe Diameter Range(mm) | 4-9 | 9-32 | 16-50 |
| Main Machine Model | SJ-30 | SJ-45 | SJ-65 |
| Screw L/D | 28: 1 | 28: 1 | 28: 1 |
| Production Capacity(kg/h) | 10 | 40 | 60 |
| Main Motor (kw) | 5.5 | 15 | 18.5 |
| Molding machine Power(kw) | 1.1 | 1.5 | 2.2 |
| Pair of Modules | 42 | 50 | 50 |
| Production Speed(m/min) | 6-10 | 8-12 | 8-12 |
