Place of Origin: | CHINA |
Brand Name: | SD Huasu Brand |
Certification: | CE, ISO |
Model Number: | pipe standard extrusion line |
Minimum Order Quantity: | 1 SET |
---|---|
Packaging Details: | standard package or as required |
Delivery Time: | 30 working days |
Payment Terms: | T/T |
Supply Ability: | 50 sets/month |
Model Number: | SJ-65 | Voltage: | 380V 50HZ 3Phase(Customized) |
---|---|---|---|
Automatic Grade: | Fully Automatic | Plastic Pipe Extrusion Line: | Corrugated Hdpe Pipe Extrusion Machinery |
Raw Material: | PE/PP/PPR/PERT/PVC | Electric Parts: | SIMENS, ABB, SCHNEILDER, EUROTHERM |
High Light: | UPVC PPR Pipe Extrusion Line,80kg/H HDPE Pipe Extrusion Line,15m/Min HDPE Pipe Extrusion Line |
This machine mainly takes PVC, PP, PE as raw materials to produce small diameter single wall corrugated pipe.
And it is developed by our company adopts gears to run modules and templates so as to realize water circulating cooling and air cooling of the products, which ensures high-speed molding,even corrugation,smooth inner and outer pipe wall.
Application:
These corrugated pipes are used for:
-Electronic wire and auto wire protection;
-Circuit of pipeline for machines;
-Water feeding and drain for washing machines ;
-Vacuum cleaner hose for collecting dusts;
-Protective pipes for lamps and lanterns wire,etc.
Pipe diameter range(mm) | 4.5-9 | 9-32 | 16-50 |
Main machine model |
SJ-30 |
SJ-50 | SJ-65 |
Main machine l/d | 30:1 | 30:1 | 30:1 |
Production capacity kg/h | 10 | 40 | 80 |
Main motor capacity kw | 4 | 11 | 18.5 |
Moiding machine capacity kw | 1.1 | 1.5 | 1.5 |
Pair of modules | 42 | 38 | 38 |
Cooling mode | Water cooling and fan cooling | ||
Production (m/min) | 6-10 | 8-12 | 8-15 |
Metering mode | inducting mode | ||
Coiling machine mode | Motor-driven Manually-operated |
