100-300 Mm HDPE Double Wall Corrugated Pipe Machine Extrusion Line Pipe Machine

100-300 Mm HDPE Double Wall Corrugated Pipe Machine Extrusion Line Pipe Machine

  • 100-300 Mm HDPE Double Wall Corrugated Pipe Machine Extrusion Line Pipe Machine
  • 100-300 Mm HDPE Double Wall Corrugated Pipe Machine Extrusion Line Pipe Machine
100-300 Mm HDPE Double Wall Corrugated Pipe Machine Extrusion Line Pipe Machine
Product Details:
Place of Origin: CHINA
Brand Name: Shandong Huasu Brand
Certification: CE, ISO9001
Model Number: Fresh Air Double Wall Corrugated Duct/Pipe
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: US $88000/ Set
Packaging Details: standard package or as required
Delivery Time: 30 working days
Payment Terms: T/T
Supply Ability: 30 sets/month
Contact Now
Detailed Product Description
Assembly Structure: Integral Type Extruder Engagement System: Full Intermeshing
Screw Channel Structure: Deep Screw Exhaust: Exhaust
Transport Package: Wood Pallet HS Code: 84779000
High Light:

300Mm Double Wall Corrugated Pipe Machine

,

100Mm Double Wall Corrugated Pipe Machine

,

HDPE Double Wall Corrugated Pipe Machine

HDPE Double Wall Corrugated Pipe Extrusion Line/Extrusion Machine/Pipe Machine

Main characters of HDPE Double Wall Corrugated Pipe Extrusion Line/Extrusion Machine/Pipe Machine:

Double wall corrugated pipe is mainly used for water drainage system. If is fully computer controlled extrusion line. It features high and stable output capacity, and highly automatic operation. For PE and PP, you can choose high efficient single or double screw extruders. For PVC, you can choose conical twin screw extruder or parallel twin screw extruder. Forming system consists of mould and corrugator. Mould blocks can be easily changed and they have air or water cooling system. The belling process is on line. High precision cutting can be guaranteed by cutting machine. The production line can also be equipped with Siemens PLC system.

Main technical parameters of HDPE Double Wall Corrugated Pipe Extrusion Line/Extrusion Machine/Pipe Machine:

Model Pipe diameter, mm PVC Output, kg/h HDPE output, kg/h Max. speed, m/min Total power, kw
SBG-300 100-300 650 600 6.5 400
SBG-500 150-500 1200 1000 6.5 580
SBG-1000 200-1000 1300 1900 3.5 610
SBG-1200 600-1200 1400 2000 1.5 800
SBG-1500 1000-1500 - 2300 0.8 900

100-300 Mm HDPE Double Wall Corrugated Pipe Machine Extrusion Line Pipe Machine 0
