Double Hollow Structural Wall HDPE Spiral Winding Corrugated / Sewerage Pipe Extrusion Machine

Double Hollow Structural Wall HDPE Spiral Winding Corrugated / Sewerage Pipe Extrusion Machine

  • Double Hollow Structural Wall HDPE Spiral Winding Corrugated / Sewerage Pipe Extrusion Machine
  • Double Hollow Structural Wall HDPE Spiral Winding Corrugated / Sewerage Pipe Extrusion Machine
Double Hollow Structural Wall HDPE Spiral Winding Corrugated / Sewerage Pipe Extrusion Machine
Product Details:
Place of Origin: CHINA
Brand Name: Shandong Huasu Brand
Certification: CE, ISO9001
Model Number: plastic pipes making extruder machine
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: US $30,000-500,000/ Set
Packaging Details: standard package or as required
Delivery Time: 30 working days
Payment Terms: T/T
Supply Ability: 30 sets/month
Contact Now
Detailed Product Description
Condition: New, Under The Order After-sales Service: Can Provide Installation And Commissioning Service
HDPE Pipe Types: Large Diameter, Structured Wall Delivery Conditions: Fob CIF CIP
Electrical Appliances: ABB, Siemese, Omron, Schneider, Sew Output: 300-1500kg/H
High Light:

HDPE Sewerage Pipe Extrusion Machine

,

Structural Wall Sewerage Pipe Extrusion Machine

,

Structural Wall pe pipe extrusion line

Double/Hollow/Structural Wall HDPE Spiral Winding Corrugated/Sewerage Pipe Extrusion Production

HDPE large diameter hollow wall spiral pipe extrusion line.
HDPE Structural wall winding pipe extrusion line.
*Double-walled corrugated pipes, with "H" structure.
*DN200-DN4000mm
*SN2, SN4,SN8,SN12.5, SN16
**HPDE extrusion spiral winding sewer pipes Appication:
- Sewage and drainage pipes
- Storm water drainage pipes
- Rain water sewage plastic pipes
- Cable protection pipes
- Civil construction sewage pipes
-Chemical storage tank
- Liquid storage tank
- Manhole wellbore

1. HDPE Large diameter spiral pipe (diameter from 200mm-4000mm) has high ring stiffness and high brunt intensity with "H" structure. It can be used for approximate 50 years and has many advantages such as low cost assembly and easy operation, with standing pressure, corrosion resistant such as acid, alkali and salt etc. It is becoming as a replacement of cement pipe and cast iron pipe nowadays. It is being widely used as sewage and drainage pipe.

2. HDPE large diameter hollow wall winding pipe machine .
**The HDPE large diameter hollow wall winding pipe extrusion line is designed with advantaged technology and improved based on long time practice experience. Diameter range can be 200-3000mm.
**Our machine is featured with comfortable operation and high performance/price ratio.
**Due to our special design, it is very convenient in transportation and installment.
**We also developed energy saving method to save energy consumption in large diameter hollow wall winding pipe extrusion.
**By adopting two sets of high efficient extruders, the output capacity is big. Our winding pipe extrusion line can make pipe with ring stiffness 4, 8, 12KN/m2. All parts precisely designed and manufactured so the whole extrusion line works stably and reliably.
**Special design for easy maintenance.
**The HDPE large diameter hollow wall winding pipe extrusion line is mainly used for producing large diameter hollow wall winding pipe.

3. Technical parameters:

Model SMSG-800 SMSG-1200 SMSG-1600 SMSG-2200/2400 SMSG-3000/4000
Extruder SJ65 SJ55 SJ90 SJ65 SJ100 SJ75 SJ120 SJ90 SJ150 SJ100
Output capacity 250-300kg/h 350-400kg/h 500-600kg/h 750-850 kg/h 1000-1500 kg/h
Pipe diameter 200-800 mm 400-1200 mm 800-1600 mm 1200-2200 mm
800-2400mm
2000-3000mm
2000-4000mm
Production speed 2-16 m/h 2-12 m/h 1-6 m/h 0.5-5 m/h 0.3-3 m/h
Installed Power 180 kw 250 kw 300 kw 400 kw 500 kw



Double Hollow Structural Wall HDPE Spiral Winding Corrugated / Sewerage Pipe Extrusion Machine 0
