Place of Origin: | CHINA |
Brand Name: | SD Huasu Brand |
Certification: | CE, ISO9001:2008, UL, QS, GMP |
Model Number: | 600H |
Minimum Order Quantity: | 1 SET |
---|---|
Packaging Details: | standard package or as required |
Delivery Time: | 30 working days |
Payment Terms: | T/T |
Supply Ability: | 50 sets/month |
Name: | HDPE Pipe Extrusion Machine | Screw Design: | Single-screw |
---|---|---|---|
Screw Material: | 38CrMoALA | Brand Name: | Shandong Huasu |
Showroom Location: | Russia, Korea, Japan Etc. | Voltage: | 380V Or As Required |
SJ-120/33: | 250KW | SJ-90/33: | 132KW |
High Light: | 3m/Min HDPE Pipe Extrusion Machine,Single Screw HDPE Pipe Extrusion Machine,3m/Min hdpe pipe production line |
This HDPE Pipe Extrusion Machine can be equipped with single screw extruder or parallel twin screw extruder. The haul off machine has three-way, four-way, six-way type. The cutting machine has blade saw cutting and planetary cutting method. Huade also supply all kinds of moulds.
Extruder | Motor | Max. Output | Note |
SJ120/33 | 250kw | 800kg/h | |
SJ90/33 | 132kw | 450kg/h |
No. | Name & Model | Quantity | |
01 | Single screw extruder SJ-120/33 | 1 set | |
02 | Single screw extruder SJ-90/33 | 1 set | |
03 | Molds | OD 200mm die head water sleeve mould block | 1 set |
OD 250mm die head water sleeve mould block | 1 set | ||
OD 500mm die head water sleeve mould block | 1 set | ||
OD 630mm die head water sleeve mould block | 1 set | ||
04 | Forming machine SBCJ-600 | 1 set | |
05 | Water cooling tank SBSC-600 with haul-off machine | 1 set | |
06 | Planetary chip free cutting machine SBQG-600 | 1 set | |
07 | Unloading bracket SBXL-600 | 1 set | |
08 | PLC control system | 1 set | |
09 | Spare parts | 1 set |
For normal speed line, please contact Ellen Liu for more details.
