Computerized Double Wall Corrugated Pipe Extrusion Line with Siemens PLC and 250-1000kg/h Capacity for Durable Pipes

  • Computerized Double Wall Corrugated Pipe Extrusion Line with Siemens PLC and 250-1000kg/h Capacity for Durable Pipes
  • Computerized Double Wall Corrugated Pipe Extrusion Line with Siemens PLC and 250-1000kg/h Capacity for Durable Pipes
  • Computerized Double Wall Corrugated Pipe Extrusion Line with Siemens PLC and 250-1000kg/h Capacity for Durable Pipes
  • Computerized Double Wall Corrugated Pipe Extrusion Line with Siemens PLC and 250-1000kg/h Capacity for Durable Pipes
  • Computerized Double Wall Corrugated Pipe Extrusion Line with Siemens PLC and 250-1000kg/h Capacity for Durable Pipes
  • Computerized Double Wall Corrugated Pipe Extrusion Line with Siemens PLC and 250-1000kg/h Capacity for Durable Pipes
Brand Name HUASU
Certification ISO,CE
Model Number SBG
Minimum Order Quantity 1 SET
Price 10,000-5,000,000
Packaging Details Standard Package
Delivery Time 30-90 days
Payment Terms TT,L/C
Supply Ability 100 line

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Extruder Capacity 250-1000kg/h Computerized Computerized
Mould Quantiy 28/36 Barrel Nitriding Depth 0.4～0.7 Mm
Gear Material 20CrMnTi PLC Siemens
Motor Siemens Capacity 8-15Kg/h
Highlight

Computerized corrugated pipe extrusion line

,

Advanced corrugated pipe production line

,

Durable corrugated pipe production line
You can tick the products you need and communicate with us in the message board.
Production Line Model SBG180* SBG260* SBG300* SBG600* SBG800* SBG1000* SBG1200* SBG1600*
Max.pipe ID diameter(mm) 180 260 300 600 800 1000 1200 1600
Min.pipe ID diameter(mm) 32 90 100 200 200 400 600 800
Total power(kw) 225 340 360 498 730 800 880 970
No.of mould blocks 28/36 28/36 36 36 36 38 38 42
Cooling way water cooling water cooling water cooling water cooling water cooling water cooling water cooling water cooling
Chain Length(mm) 6333.5 6333.5 6333.5 6333.5 6333.5 6385.3 6385.3 7389
Length of Production Line(mm) 30000 30000 32000 33000 37000 38000 39000 41000
Width of Production Line 3000 3000 3500 5500 6800 7400 8200 9000
Height of Production Line (mm) 1000 1000 1100 1250 1400 1600 1800 1950
Corrugator weight(kg) 5000 5000 7000 11000 125000 16000 18000 20000
Center height of Corrugator 1000 1000 1100 1250 1400 1600 1800 1950
Extruder 1 Model SJ65/33 SJ75/33 SJ75/33 SJ90/33 SJ90/33 SJ90/33 SJ90/36 SJ90/36
Extruder 2 Model SJ75/33 SJ90/33 SJ90/33 SJ120/33 SJ120/33 SJ120/33 SJ120/36 SJ150/36
Leave a Message
Production Line Model SBG180* SBG260* SBG300* SBG600* SBG800* SBG1000* SBG1200* SBG1600*
Product Description
Computerized Double Wall Corrugated Pipe Production Line
Advanced Extrusion Technology for Durable Pipes
The Double Wall Corrugated Pipe Extrusion Line is a comprehensive turnkey solution engineered for manufacturing high-quality double wall corrugated pipes. This state-of-the-art production system incorporates advanced features and precision components to ensure optimal efficiency and superior product quality.
Key Features
  • Product Name: Double Wall Corrugated Pipe Extrusion Line
  • Extruder Capacity: 250-1000kg/h
  • High-Durability Barrel: Hardness HV>940
  • Premium Siemens Motor System
  • Type: Double Wall Corrugated Pipe Extrusion Line
  • Deep Barrel Nitriding: 0.4～0.7 mm
Technical Specifications
Parameter Specification
Control System PLC Control
Engagement System Full Intermeshing
Capacity 8-15 Kg/h
Extruder Capacity 250-1000 kg/h
Screw Design Single-screw
Gear Material 20CrMnTi
PLC Brand Siemens
Dimensions 29*6.8*5 meters
Barrel Hardness HV>940
Production Advantages
Controlled by a sophisticated PLC system, this extrusion line provides precise monitoring and adjustment capabilities for optimal production parameters. The full intermeshing engagement technology ensures uniform and smooth pipe corrugation, delivering superior structural integrity and performance.
HUASU SBG Model Specifications
Model: SBG Double Wall Corrugated Pipe Extrusion Line
Certifications: ISO and CE Certified
Minimum Order: 1 Set
Delivery Time: 30-90 Days
Payment Terms: TT and L/C Accepted
Mould Options: 28 or 36 Quantity Configurations
With its compact 29*6.8*5 meter footprint, the extrusion line is designed for operational efficiency and easy maintenance. As leading manufacturers in corrugated pipe machinery, we deliver reliable performance, consistent quality, and cost-effective production solutions tailored to your manufacturing requirements.
