Automated Double Wall Corrugated Pipe Production Line
| Brand Name | HUASU |
|---|---|
| Certification | ISO,CE |
| Model Number | SBG |
| Minimum Order Quantity | 1 SET |
| Price | USD100,000-5,000,000 |
| Packaging Details | Standard Package |
| Delivery Time | 30-90 |
| Payment Terms | TT,L/C |
| Supply Ability | 1000 set per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Usage | Water Supply Pipe Line,electric Power Threading And Drainage Pipe Extrusion Line | Type | Double Wall Corrugated Pipe Extrusion Line |
|---|---|---|---|
| Capacity | 8-15Kg/h | Extruder Capacity | 250-1000kg/h |
| Motor | Siemens | Computerized | Computerized |
| Mould Quantiy | 28/36 | Dimension | 29*6.8*5M |
| Highlight | Full Intermeshing Engagement System Extrusion Line,Double Wall corrugated pipe production line,0.7mm Barrel Nitriding Depth Extrusion Line |
||
You can tick the products you need and communicate with us in the message board.
| Production Line Model | SBG180* | SBG260* | SBG300* | SBG600* | SBG800* | SBG1000* | SBG1200* | SBG1600* | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Max.pipe ID diameter(mm) | 180 | 260 | 300 | 600 | 800 | 1000 | 1200 | 1600 | ||
| Min.pipe ID diameter(mm) | 32 | 90 | 100 | 200 | 200 | 400 | 600 | 800 | ||
| Total power(kw) | 225 | 340 | 360 | 498 | 730 | 800 | 880 | 970 | ||
| No.of mould blocks | 28/36 | 28/36 | 36 | 36 | 36 | 38 | 38 | 42 | ||
| Cooling way | water cooling | water cooling | water cooling | water cooling | water cooling | water cooling | water cooling | water cooling | ||
| Chain Length(mm) | 6333.5 | 6333.5 | 6333.5 | 6333.5 | 6333.5 | 6385.3 | 6385.3 | 7389 | ||
| Length of Production Line(mm) | 30000 | 30000 | 32000 | 33000 | 37000 | 38000 | 39000 | 41000 | ||
| Width of Production Line | 3000 | 3000 | 3500 | 5500 | 6800 | 7400 | 8200 | 9000 | ||
| Height of Production Line (mm) | 1000 | 1000 | 1100 | 1250 | 1400 | 1600 | 1800 | 1950 | ||
| Corrugator weight(kg) | 5000 | 5000 | 7000 | 11000 | 125000 | 16000 | 18000 | 20000 | ||
| Center height of Corrugator | 1000 | 1000 | 1100 | 1250 | 1400 | 1600 | 1800 | 1950 |
Product Description
Automated Double Wall Corrugated Pipe Production Line
Product Description:
The Double Wall Corrugated Pipe Extrusion Line is a state-of-the-art machine designed for efficient and high-quality double wall corrugated pipe production. This computerized extrusion line is equipped with advanced technology to ensure precision and reliability in the manufacturing process.
As one of the best double wall corrugated pipe machine manufacturers, we have developed this extrusion line to meet the demanding requirements of the industry. The machine is specifically designed for the production of double wall corrugated pipes, which are widely used in various applications such as drainage systems, cable protection, and more.
The extrusion line features a single-screw design, which offers excellent control over the extrusion process. This design ensures consistent output quality and allows for easy operation and maintenance. The engagement system of the machine is full intermeshing, providing superior mixing and compounding of materials for optimal pipe performance.
With this corrugated pipe extrusion line, manufacturers can achieve high productivity and cost efficiency in their production processes. The computerized controls enable precise adjustment of key parameters such as temperature, speed, and pressure, ensuring consistent pipe quality and dimensional accuracy.
Whether you are a seasoned manufacturer looking to upgrade your production line or a newcomer seeking to enter the market, this double wall corrugated pipe extrusion line is a reliable and efficient solution. Its advanced features and robust construction make it a versatile machine capable of meeting a wide range of production needs.
In conclusion, the Double Wall Corrugated Pipe Extrusion Line is a cutting-edge solution for manufacturers in the corrugated pipe industry. With its computerized controls, single-screw design, and full intermeshing engagement system, this extrusion line offers unmatched precision and efficiency in double wall corrugated pipe production.
Features:
- Product Name: Double Wall Corrugated Pipe Extrusion Line
- Capacity: 8-15Kg/h
- Dimension: 29*6.8*5M
- Type: Double Wall Corrugated Pipe Extrusion Line
- Usage: Corrugated Pipe
- PLC: Siemens
Technical Parameters:
| Barrel Nitriding Depth | 0.4～0.7 mm |
| Barrel Hardness | HV>940 |
| Type | Double Wall Corrugated Pipe Extrusion Line |
| Usage | Corrugated Pipe |
| Capacity | 8-15 kg/h |
| PLC | Siemens |
| Gear Material | 20CrMnTi |
| Mould Quantity | 28/36 |
| Screw Design | Single-screw |
| Computerized | Computerized |
Applications:
When considering the best double wall corrugated pipe machine manufacturers, the HUASU SBG Double Wall Corrugated Pipe Extrusion Line from China stands out as a top choice. This product is designed to meet the high standards demanded in various applications across industries.
The SBG extrusion line is suitable for a wide range of product application occasions and scenarios. Its durable construction and reliable performance make it ideal for projects requiring double wall corrugated pipes with precise specifications. With ISO and CE certifications, this machine ensures quality and compliance with international standards.
Whether you need to produce drainage pipes, cable protection conduits, or other corrugated pipe products, the HUASU SBG line offers versatility and efficiency. The single-screw design, combined with a PLC control system, allows for precise control over the extrusion process, resulting in high-quality output.
With a minimum order quantity of just 1 set and standard packaging details, acquiring the SBG extrusion line is convenient and hassle-free. The gear material of 20CrMnTi ensures durability and longevity, while the hardness of the barrel exceeding HV940 guarantees robust performance even in demanding conditions.
For those in search of a computerized solution with a quick delivery time of 30-90 days, the HUASU SBG Double Wall Corrugated Pipe Extrusion Line offers efficiency and reliability. Payment terms such as TT and L/C provide flexibility for procurement, making it accessible to a wide range of customers.
